Combines an inductor and a transformer into a single ultra-compact/miniaturized, lightweight component, regardless of the inductance value, for a seamless integration.
- High Power Applications (up to 300kW)
- High Frequency (10-500kHz): fits next-generation semiconductors (SiC, GaN) : Enables compact, lightweight designs.
- High Efficiency: minimizing losses, achieving efficiencies above 99% even at high frequencies.
- Lower Total cost of ownership: Ensuring straightforward integration and optimized system costs.
- EMI Reduction: Enhances electromagnetic compatibility for reliable operation.
TECHNICAL CHARACTERISTICS
3 Phase 24 kVA Integrated Component (Transformer + Inductors) 360/27 V @ 100kHz.
Dual Active Bridge Transformer 2kW / 10:1 / 300 kHz and Chokes 10µH
Meet the Challenges in Converter Development:
- Miniaturization: Designing smaller systems without compromising performance.
- Thermal Management: Efficiently managing heat to enhance durability and efficiency.
- Cost-Effectiveness: Balancing efficiency enhancements with cost-effective solutions.
Exxelia’s commitment to the development of these new technologies shows its willingness to anticipate the needs of advances power electronics.
